Stainless steel wire mesh for filtering Stainless steel wire mesh for extra width for filtering Minigroove stainless steel wire meshStainless steel crimped mesh Wire mesh deep processing productStainless Steel Wire Mesh For Filtering
Product classification: high mesh stainless steel wire mesh(mesh 325-635)
General stainless steel wire mesh (mesh 2-300)
Material: stainless steel wire 304,304L,316,316L,2520,2080 and so on
Width: 0.5-8M (we can cut to 0.05-0.99M ribbon according to customer’s requirement )
Weaving: plain weave, twill weave and dutch weave (we can make special type according to customer’s requirement)
Specification: plain weave mesh 2-300
Twill weave mesh 200-635
Type: roll, square hole, round (we can process it to filtering material )
Characteristic: acid resistant, alkali-resisting, heat-resistant, tensile, wear-resisting
Application: widely used in sieving and filtering on acid and alkali condition, petroleum industry for Net mud, chemical fiber industry for sieving, environment protection, mining, aviation realm, paper making, electronic industry, metallurgy, electroplating industry for acid cleaning, food , medicine and machinofacture
Our factory accept customer ’s material for processing and OEM, special specification, weave type, width and mesh can make according to customer’s requirement.
high mesh stainless steel wire mesh(mesh 325-635)
General stainless steel wire mesh (mesh 2-300)
Detailed specification:
(plain weave) specification parameter table |
||||||
mesh |
Wire diameter |
aperture |
Opening area |
Weight(lbs)/100 square foot |
||
inch |
mm |
Inch |
mm |
|||
2X2 |
.063 |
1.60 |
.437 |
11.10 |
76.4 |
51.2 |
3X3 |
.054 |
1.37 |
.279 |
7.09 |
70.1 |
56.7 |
4X4 |
.063 |
1.60 |
.187 |
4.75 |
56.0 |
104.8 |
4X4 |
.047 |
1.19 |
.203 |
5.16 |
65.9 |
57.6 |
5X5 |
.041 |
1.04 |
.159 |
4.04 |
63.2 |
54.9 |
6X6 |
.035 |
.89 |
.132 |
3.35 |
62.7 |
48.1 |
8X8 |
.028 |
.71 |
.097 |
2.46 |
60.2 |
41.1 |
10X10 |
.025 |
.64 |
.075 |
1.91 |
56.3 |
41.2 |
10X10 |
.020 |
.51 |
.080 |
2.03 |
64.0 |
26.1 |
12X12 |
.023 |
.584 |
.060 |
1.52 |
51.8 |
42.2 |
12X12 |
.020 |
.508 |
.063 |
1.60 |
57.2 |
31.6 |
14X14 |
.023 |
.584 |
.048 |
1.22 |
45.2 |
49.8 |
14X14 |
.020 |
.508 |
.051 |
1.30 |
51.0 |
37.2 |
16X16 |
.018 |
.457 |
.0445 |
1.13 |
50.7 |
34.5 |
18X18 |
.017 |
.432 |
.0386 |
.98 |
48.3 |
34.8 |
20X20 |
.020 |
.508 |
.0300 |
.76 |
36.0 |
55.2 |
20X20 |
.016 |
.406 |
.0340 |
.86 |
46.2 |
34.4 |
24X24 |
.014 |
.356 |
.0277 |
.70 |
44.2 |
31.8 |
30X30 |
.013 |
.330 |
.0203 |
.52 |
37.1 |
34.8 |
30X30 |
.012 |
.305 |
.0213 |
.54 |
40.8 |
29.4 |
30X30 |
.009 |
.229 |
.0243 |
.62 |
53.1 |
16.1 |
35X35 |
.011 |
.279 |
.0176 |
.45 |
37.9 |
29.0 |
40X40 |
.010 |
.254 |
.0150 |
.38 |
36.0 |
27.6 |
50X50 |
.009 |
.229 |
.0110 |
.28 |
30.3 |
28.4 |
50X50 |
.008 |
.203 |
.0120 |
.31 |
36.0 |
22.1 |
60X60 |
.0075 |
.191 |
.0092 |
.23 |
30.5 |
23.7 |
60X60 |
.007 |
.178 |
.0097 |
.25 |
33.9 |
20.4 |
70X70 |
.0065 |
.165 |
.0078 |
.20 |
29.8 |
20.8 |
80X80 |
.0065 |
.165 |
.0060 |
.15 |
23.0 |
23.2 |
80X80 |
.0055 |
.140 |
.0070 |
.18 |
31.4 |
16.9 |
90X90 |
.005 |
.127 |
.0061 |
.16 |
30.1 |
15.8 |
100X100 |
.0045 |
.114 |
.0055 |
.14 |
30.3 |
14.2 |
100X100 |
.004 |
.102 |
.0060 |
.15 |
36.0 |
11.0 |
100X100 |
.0035 |
.089 |
.0065 |
.17 |
42.3 |
8.3 |
110X110 |
.0040 |
.1016 |
.0051 |
.1295 |
30.7 |
12.4 |
120X120 |
.0037 |
.0940 |
.0064 |
.1168 |
30.7 |
11.6 |
150X150 |
.0026 |
.0660 |
.0041 |
.1041 |
37.4 |
7.1 |
160X160 |
.0025 |
.0635 |
.0038 |
.0965 |
36.4 |
5.94 |
180X180 |
.0023 |
.0584 |
.0033 |
.0838 |
34.7 |
6.7 |
200X200 |
.0021 |
.0533 |
.0029 |
.0737 |
33.6 |
6.2 |
250X250 |
.0016 |
.0406 |
.0024 |
.0610 |
36.0 |
4.4 |
270X270 |
.0016 |
.0406 |
.0021 |
.0533 |
32.2 |
4.7 |
300X300 |
.0051 |
.0381 |
.0018 |
.0457 |
29.7 |
3.04 |
| (twill weave) specification parameter table | ||||||
mesh |
Wire diameter |
aperture |
Opening area |
Weight(lbs) /100 square foot |
||
inch |
mm |
Inch |
mm |
|||
200X200 |
.0021 |
.0533 |
.0029 |
.0737 |
33.6 |
6.2 |
250X250 |
.0016 |
.0406 |
.0024 |
.0610 |
36.0 |
4.4 |
270X270 |
.0016 |
.0406 |
.0021 |
.0533 |
32.2 |
4.7 |
300X300 |
.0051 |
.0381 |
.0018 |
.0457 |
29.7 |
3.04 |
325X325 |
.0014 |
.0356 |
.0017 |
.0432 |
30.0 |
4.40 |
400X400 |
.0010 |
.0254 |
.0015 |
.370 |
36.0 |
3.3 |
500X500 |
.0010 |
.0254 |
.0010 |
.0254 |
25.0 |
3.8 |
635X635 |
.0008 |
.0203 |
.0008 |
.0203 |
25.0 |
2.63 |
| Stainless steel chemical constitution table | ||||||||
AISI |
Chemical composition(%) |
|||||||
|
C |
Si |
Mn |
P |
S |
Ni |
Cr |
Mo |
304 |
≤0.08 |
≤1.00 |
≤2.00 |
≤0.045 |
≤0.030 |
8.00~10.50 |
18.00~20.00 |
- |
304L |
≤0.030 |
≤1.00 |
≤2.00 |
≤0.045 |
≤0.030 |
9.00~13.50 |
18.00~20.00 |
- |
316 |
≤0.045 |
≤1.00 |
≤2.00 |
≤0.045 |
≤0.030 |
10.00~14.00 |
10.00~18.00 |
2.00 |
316L |
≤0.030 |
≤1.00 |
≤2.00 |
≤0.045 |
≤0.030 |
12.00~15.00 |
16.00~18.00 |
2.00 |
